32000 GPD Reverse Osmosis Water Treatment System
Overview:
The 32000 GPD Reverse Osmosis (RO) Water Treatment System is designed for commercial applications, offering a high-efficiency solution for purifying water from sources like tap or well water. Manufactured by Fenigal and available for OEM customization, this system utilizes state-of-the-art reverse osmosis technology to remove high levels of dissolved solids, providing purified water for various industries including food and beverage production, pharmaceuticals, and water purification.
Key Features:
High Capacity: Capable of producing up to 32,000 gallons per day (GPD) of purified water.
Advanced Filtration: Features high-efficiency TW RO membranes, designed for superior salt removal.
Energy Efficient: Operates at a pressure range of 150-250 psi, ensuring optimal performance in high TDS water conditions.
Wide Application Range: Suitable for industries like pharmaceuticals, food and beverage production, electronics, and more.
Durable Construction: Built with SS304/SS316L stainless steel and carbon steel for long-lasting reliability.
Customizable Voltage: Options for 380V, 415V, or 220V power configurations, making it adaptable to various environments.
Specifications:
Recovery Rate: 65-75%
Feed TDS/ppm: <2,000
Feed Water Temperature: 5-35°C
pH Range: 4-9
Turbidity: <5 TSS/mg/L
Silt Density Index: <3
Free Chlorine: 0 mg/L
Dissolved Iron: <0.1 mg/L
Membrane Options: Vontron, Hydranautics, or DOW 4040
Control System: Manual, electronic, or PLC-based control
Warranty: 1 year
Materials: Stainless steel (SS304/SS316L), carbon steel
Applications: Water filtration, desalination, drinking water, food and beverage, pharmaceutical, industrial water treatment
Model Options:
| Model | Permeate Flow Rate | Pressure Vessel Qty. | Membrane Qty. | Motor Rating | Dimensions (L x W x H) |
|---|
| RON-3340 | 13,000 GPD | 3 | 9 | 3 hp / 2.2 kw | 136x43x60 inches (345x109x152 cm) |
| RON-5240 | 15,000 GPD | 5 | 10 | 5 hp / 3 kw | 96x43x60 inches (244x109x152 cm) |
| RON-4340 | 18,000 GPD | 4 | 12 | 5 hp / 2.2 kw | 136x43x60 inches (345x109x152 cm) |
| RON-5340 | 22,000 GPD | 5 | 15 | 5 hp / 3 kw | 136x43x60 inches (345x109x152 cm) |
| RON-8240 | 24,000 GPD | 8 | 16 | 5 hp / 3 kw | 96x43x68 inches (244x109x173 cm) |
| RON-6340 | 27,000 GPD | 6 | 18 | 5 hp / 3 kw | 136x43x68 inches (345x109x173 cm) |
| RON-7340 | 32,000 GPD | 7 | 21 | 5 hp / 4 kw | 136x43x68 inches (345x109x173 cm) |
Applications of Reverse Osmosis System:
Metal Finishing & Electronics Manufacturing: Provides purified water for cleaning and rinsing.
Beverage Production & Bottled Water: Ensures safe drinking water free from contaminants.
Pharmaceutical Industry: Ideal for water used in production processes and laboratory testing.
Mining & Chemical Industries: Facilitates water treatment for mining operations and chemical blending.
Power Plants & Cooling Towers: Offers water treatment for boiler feed and cooling purposes.
Food & Beverage Industries: Ensures pure water for product rinsing, ice manufacturing, and other processes.
Advantages:
High Desalination Rate: 99% to 99.7% desalination efficiency.
Flexible Voltage Options: Customizable voltage settings to meet specific power requirements.
Advanced Control Panel: Equipped with microprocessor-based control panels, LCD screens, pressure gauges, and flow meters.
Durability & Quality: Constructed from high-grade stainless steel for durability and long-term operation.
Why Choose Fenigal's 32000 GPD Reverse Osmosis System?
Our systems are engineered for reliability and efficiency. Whether you need a commercial RO system for food production, industrial use, or safe drinking water, Fenigal provides customizable solutions that meet the highest standards. With competitive pricing and quick delivery times, we aim to exceed your expectations.
Contact Us Today for More Information!
