4TPH 25200GPD Industrial Reverse Osmosis Water Treatment System | Fenigal Brand OEM Available
Product Description:
This 4 Ton per Hour (25200 Gallons Per Day) Reverse Osmosis Water Treatment System is designed for industrial water purification applications. Utilizing advanced RO membrane technology, it effectively removes dissolved solids, organics, colloidal particles, color, nitrate, and bacteria from feed water. It is widely used in industries such as food and beverage processing, electronics manufacturing, and pharmaceuticals. The system features a modular skid-mounted design for easy installation and flexible operation. It is compatible with various well-known RO membrane brands like DOW, Vontron, and Hydranautics to meet diverse customer needs.
Process Flow:
Raw Water → Raw Water Tank → Raw Water Pump → Quartz Sand Filter → Activated Carbon Filter → Softener (Optional) → Precision Filter → High Pressure Pump → RO System → Pure Water Tank → Booster Pump → UV Sterilizer / Ozone Generator (Optional) → Water Distribution Points
Product Specifications:
| Parameter | Description |
|---|
| Model Number | RO-4TPH, 1-17 |
| Permeate Flow | 4,000L/h (25200GPD) |
| Recovery Rate | 60~65% |
| Desalination Rate | 99%~99.7% |
| Feed Water TDS | <2,000 ppm |
| Water Temperature | 5~35˚C |
| Design | Skid-Mounted |
| Material | SS304 / SS316L Stainless Steel, Carbon Steel |
| Control System | Manual / Electronic / PLC |
| RO Membranes | Vontron, Hydranautics, DOW (4040 Model) |
| Membrane Housing | 8080 Stainless Steel |
| Raw Water & High Pressure Pumps | CNP Brand |
| Filter System | 3 FRP Vessels: Sand Filter, Carbon Filter, Softener |
| Security Filter | Stainless Steel Housing with 5μm PP Cartridge |
| Power Supply | 380V / 415V / 220V (Customizable) |
| Power Consumption | Approx. 5.0 kW |
| Certifications | CE, NSF, etc. |
| Place of Origin | China |
| Brand Name | Fenigal or OEM |
| Minimum Order Quantity | 1 Set |
| Packaging | Standard Export Wooden Crate/Carton or Film-Wrapped Naked |
| Delivery Time | 15~30 Days |
| Payment Terms | T/T, PayPal, Western Union, etc. |
| Monthly Supply Capacity | 50 Sets/Month |
For quotations, technical support, or to become a distributor, please contact us for more information.
